AMGO Double Wide 4-post lift – 9,000 lb Capacity | 409-DP

Double Your Parking Capacity: AMGO 409-DP 9,000 lb Double-Wide 4-Post Parking Lift

Finding enough parking space for multiple vehicles can be a constant struggle. Especially if you own a shop, have a multi-car household, or store vehicles for clients. Traditional lifts often take up too much room, leaving little space for other work or storage needs. The AMGO 409-DP solves that problem by letting you store two vehicles side-by-side on each platform, doubling your capacity without increasing your footprint. With its 9,000 lb lifting capacity and robust construction, this lift delivers convenience and performance in a space-saving design. Double wide 4-post lifts solve a real problem standard-width lifts can't: the cramped door-clearance and tight loading geometry that makes standard 4-post lifts awkward for full-size trucks and SUVs.

This double parking lift isn’t just about capacity. It’s engineered for reliability and safety. AMGO’s patented concealed safety lock control device, combined with a dual safety system, keeps every lift cycle secure and stable. The low-profile platform height makes loading and unloading easier, even for low-clearance sports cars, while non-slip diamond platforms keep tires planted during movement. Wider column spacing gives extra room for door swing during loading and service, with the 9K capacity handling typical passenger cars and light trucks, and most light commercial vehicles. The 110V plug-in operation works in standard residential outlets.

Designed with AMGO’s signature double “5” shaped columns, foldable drive-on ramps, and heavy-duty components, the 409-DP balances strength with user-friendly features. It’s backed by AMGO’s 5-3-2 warranty, so you can invest with confidence knowing you’re covered for years to come. Whether it’s for a home garage or a commercial parking facility. For owners with full-size pickups, work vans, or wider SUVs, the 409-DP eliminates the door-clearance gymnastics standard 4-post lifts force during loading.

Need a different capacity or configuration? Compare all 4 post car lifts, browse the full Car Lifts collection, or read our 2-Post vs 4-Post guide to pick the right style. Questions? Call (470) 208-2754.

Benefits of the AMGO 409-DP Double-Wide Parking Lift

Free Up Garage SpaceStack a project car on top of your daily driver, or store seasonal vehicles vertically to reclaim floor space. The 4-post storage configuration is purpose-built for vertical vehicle parking.Service & Storage in OneLift travel handles tire rotations, brake jobs, and oil changes in addition to long-term storage. One lift covering both jobs.Total MobilityIncluded caster kit lets you roll the lift across the garage, swap bays, or stash it against a wall when you need the floor.Protects the Lower VehicleDrip trays catch oil, coolant, and fluids before they reach the vehicle parked underneath. Saves your lower car's paint.Plug-In 110V OperationStandard household power, no electrician or 220V circuit required. Lifts in well under a minute at full capacity.Field-Proven DesignMechanical locks with single-point release across an established AMGO storage-lift platform. Built for years of reliable cycling.

Key Features of the AMGO 409-DP Double-Wide Lift You'll Love:

• Dual-Vehicle Storage Capacity: Hold two vehicles side-by-side per platform to instantly double parking density without extra floor space. The dual-vehicle configuration effectively doubles parking density per lift, the highest space-efficiency option in the 4-post storage category.

• Low-Profile Platform Design: Minimum platform height of 5 15/16" makes loading smooth. Even for low-clearance sports cars. Low-profile drive-on accommodates sports cars and lowered vehicles that won't clear standard 4-post platform heights.

• Patented Concealed Safety Lock Control: Protected internal mechanism with manual single-point release for quick, safe operation. Concealed mechanism design protects the safety system from incidental damage during loading and keeps the bay looking professional.

• Dual Safety System: Primary mechanical locks plus a cable-slack secondary device for redundancy and confidence. Cable-slack backup provides redundant safety. If the primary mechanical lock fails, the secondary system engages automatically.

• Heavy-Duty Structural Strength: Double “5” shaped columns and non-slip diamond platforms provide stability and long-term durability. Double S-shaped column geometry distributes the dual-vehicle load across the structural columns without flex or torsional fatigue.

• Foldable Drive-On Ramps: All four platforms include foldable ramps that ease entry and tuck away to save space. Foldable ramps tuck flat against the platforms when not in use, freeing floor space for other equipment between storage cycles.

Minimum Garage Requirements

✔ Ceiling Height: At least 88" (7'4") recommended✔ Floor Space: 208 1/16" L x 190 9/16" W (17'4" x 15'11")✔ Concrete Thickness: Minimum 4" (101.6 mm)✔ Concrete Strength: Minimum 3,000 PSI compressive✔ Electrical: 1.0 HP 110V/60Hz standard, 2.0 HP 220V/60Hz optional upgrade✔ Post Height: 82" (6'10") (measure before ordering)

✔ Ceiling Height: At least 88" (7'4") recommended✔ Floor Space: 208 1/16" L x 190 9/16" W (17'4" x 15'11")✔ Concrete Thickness: Minimum 4" (101.6 mm)✔ Concrete Strength: Minimum 3,000 PSI compressive✔ Electrical: 1.0 HP 110V/60Hz standard, 2.0 HP 220V/60Hz optional upgrade✔ Post Height: 82" (6'10") (measure before ordering)

*Concrete must meet the manufacturer's minimum requirements as specified above. Installing this lift on inadequate concrete may result in serious injury or death. It is the customer's responsibility to verify concrete thickness and strength prior to purchase and installation. Stacking taller vehicles vertically may require additional ceiling height. Measure your specific vehicles before ordering.

AMGO 409-DP Frequently Asked Questions

How does a double-wide 4-post lift work?

Two parking platforms share one set of four columns: park two vehicles on top, two underneath -- four cars in roughly two bays' width (190-9/16" overall). Total capacity is 9,000 lbs with up to 6,000 lbs on either platform.

How much ceiling height do I need?

The columns stand just 82-7/8", so 88" (7'4") of ceiling covers lifting alone -- one of the lowest-profile double-wides available. Stacking two vehicles per side takes more; measure your tallest pair before ordering.

Which AMGO 4-post is right for me?

This 409-DP is the standard-height four-car solution. Need taller stacking and longer runways? The 409-DPX raises the columns to 96-5/8" and stretches to 238". Only storing two vehicles? A single-platform 408-P or 409-HP costs less and takes half the width.

What power does it need?

A 1.0 HP 110V/60Hz standard power unit (2.0 HP 220V/60Hz upgrade available) with a 100-second rise. Plan a 220V circuit where the power column will sit.

Can I do repair work on the 409-DP?

Light service works from the runways -- add the J5H 5,000 lb rolling jack for wheels-free work and the drip tray set to protect vehicles parked below. Storing outdoors or under a carport? The motor cover protects the power unit.

Do I need to bolt it to the floor?

No -- it's free-standing on concrete at least 4" thick at 3,000 PSI. Anchoring is optional for permanent installs.

Is the AMGO 409-DP worth it?

Four parking spots on two bays of concrete, backed by 5 years on structure, 3 on hydraulics, and 2 on electrical. See the Reviews tab above for buyer feedback, and our 2-Post vs 4-Post guide if you're still choosing a style.
